OR Gate Implementation using Diode – Paper Circuit Project

OR Gate Implementation using Diode – Paper Circuit Project Abstract: The OR Gate Implementation using Diodes is a simple digital electronics model designed using paper circuit technology to demonstrate the basic working of an OR logic gate. In this project, diodes are used to perform logical OR operation without using any integrated circuits. The circuit accepts two input signals (A and B). When either one or both inputs are HIGH, the diode corresponding to that input conducts and the output becomes HIGH. The output remains LOW only when both inputs are LOW. An LED indicator is used at the output to visually display the logic result. By constructing the circuit on paper using copper tape instead of a PCB, the project becomes low-cost, safe, solder-free, and easy to understand. This model is ideal for learning basic digital logic concepts, diode applications, and introductory electronics. Package Includes: 1 Piece –OR Gate Implementation using Diode (Working Project Without Battery) Note: Project Image only Illustration Purpose. The project may be the same or maybe an improved Version. We only provide batteries when students pick up their projects from our lab. Batteries aren’t included in shipped orders because our shipping partner doesn’t allow them.
